High-Capacity Plug-and-Play Gigabit PoE+ Expansion for Desktop Networks
The TRENDnet 8-Port Gigabit PoE+ Switch (TPE-TG80g) offers a highly reliable, cost-effective solution for expanding local network footprints while delivering power over existing cabling infrastructure. Engineered for small-to-medium offices, home work environments, and edge device installations, this unmanaged desktop switch features 8 full Gigabit Ethernet ports that automatically detect and supply power to connected PoE hardware.
Equipped with a sturdy metal enclosure and an advanced fanless architecture, the TPE-TG80g delivers zero-decibel silent operation, making it ideal for desktop environments or noise-sensitive open office floor plans. With a high-capacity PoE power budget exceeding 120 Watts, this unmanaged Layer 2 switch effortlessly supports intensive edge device deployments—such as high-power wireless access points, pan-tilt-zoom (PTZ) IP surveillance cameras, and multi-line VoIP telephony setups—without complex software configurations.
Key Product Features
- All-Gigabit PoE+ Matrix: Outfitted with 8 x 10/100/1000 Mbps RJ-45 ports that support both IEEE 802.3af (PoE) and IEEE 802.3at (PoE+) standards, delivering up to 30W of power per port.
- High-Capacity Power Budget: Robust 120W+ total system PoE power budget ensures ample power allocation across multiple high-draw devices simultaneously.
- Silent Fanless Construction: Zero fan noise engineering allows the switch to sit directly on a desk, shelf, or workspace without distracting or disturbing personnel.
- Intelligent Energy Savings: Integrated GREENnet power-saving technology reduces energy footprint automatically by optimizing power delivery to ports based on link status and cable length.
- Rugged Metal Housing: Encased in a compact, durable steel chassis designed to handle everyday physical stress while providing optimal passive heat dissipation.
- Instant Plug-and-Play setup: Requires zero software installation, drivers, or complex administrative assignments; simply connect network cables and power up for full line-speed performance.
Technical Specifications
| Attribute | Specification Details |
|---|---|
| Hardware Interface | 8 x Gigabit PoE/PoE+ Ports (RJ-45 Auto-MDIX) | Front-facing LED status diagnostic lights |
| Network Standards | IEEE 802.3, 802.3u, 802.3x, 802.3ab, 802.3af (PoE), 802.3at (PoE+), 802.3az (Energy Efficient Ethernet), 802.1p CoS |
| Switching Capacity | 16Gbps non-blocking switching fabric fabric bandwidth layout |
| Forwarding Rate | Up to 11.9 Mpps data transmission speed (based on standard 64-byte packet profiles) |
| PoE Pin Mapping | Alternative Mode A structure (Pins 1 & 2 for power+, Pins 3 & 6 for power-) |
| Structural Buffer & Tables | Up to 128KB data packet RAM buffer | Up to 4K MAC address lookup entries array | 9K Jumbo Frame architecture support |
| Power Input Profiles | 100 - 240 V AC, 50/60 Hz switching adapter input | Base consumption: 5.3W (without any PoE output devices active) |
| Environmental Tolerance | Operating Temperature: 0° to 45° C (32° to 113° F) | Maximum relative humidity parameters: 90% non-condensing |
| Chassis Dimensions | Compact metal desktop footprint (approx. 150 x 96 x 28 mm / 5.9 x 3.8 x 1.1 in.) | Weight: 400 g (14 oz.) |
| Certifications & Cover | CE, FCC compliant | TAA + NDAA compliant | TRENDnet Manufacturer Lifetime Protection Warranty |
