Smart Managed Power and L2 Traffic Control for Growing Networks
The TRENDnet TPE-1620WS 20-Port Gigabit Web Smart PoE+ Switch delivers the ideal balance of high-capacity power distribution and advanced Layer 2+ network management for small-to-medium businesses. Engineered to accommodate growing data infrastructures, this web-smart solution provides network administrators with total visibility and granular software controls without the complexity or extreme cost overhead of enterprise-tier fully managed platforms.
Hardware features include 16 dedicated Gigabit PoE+ ports backed by a sturdy 185-Watt total power budget, delivering up to 30W per port to run smart VoIP lines, advanced IP security cameras, and dual-band wireless access points. For flexible backend growth, 4 shared Gigabit ports (usable as standard copper RJ-45 or high-speed fiber SFP slots) provide high-bandwidth uplink links to preserve your system performance. Enhanced with an intuitive web browser GUI, administrators can easily isolate vital assets with 802.1Q VLANs, prioritize traffic using Quality of Service (QoS) protocols, and monitor individual port analytics.
Key Product Features
- 16 x Dedicated Gigabit PoE+ Ports: Delivers robust data and up to 30W of auto-sensing IEEE 802.3at power per port directly over standard network cables.
- 4 x Shared Gigabit Combo Ports: Flexible infrastructure deployment options using 4 shared ports configurable as either RJ-45 copper lines or SFP fiber modules for backhauls.
- Intuitive Web Smart Management: Easily manage and configure your local network via an accessible web-based GUI featuring advanced traffic control, diagnostic utilities, and configuration backup options.
- L2+ Traffic Optimization & Segregation: Features advanced network tools including LACP link aggregation, IGMP Snooping, Port Bandwidth Management, and 802.1Q VLAN tagging for secure network isolation.
- Automated PD Alive Check: Smart self-healing technology continuously monitors active PoE devices and automatically attempts to reboot unresponsive hardware to reduce offline system downtime.
- Durable 1U Rackmount Housing: Heavy-duty industrial metal chassis includes a complete 19-inch 1U server rack brackets kit for professional installation.
Technical Specifications
| Attribute | Specification Details |
|---|---|
| Device Interfaces | 16 x Gigabit PoE+ ports, 4 x Shared Gigabit ports (RJ-45 / SFP slots), LED diagnostic indicators |
| Standards Compliance | IEEE 802.3, 802.3u, 802.3x, 802.3ab, 802.3ad, 802.3af (PoE), 802.3at (PoE+), 802.3az (Energy Efficient Ethernet) |
| Switching Capacity | 40Gbps switch fabric bandwidth capacity (Forwarding rate: 29.8Mpps utilizing 64-byte packet profiles) |
| Memory & Hardware Tables | Data RAM Buffer: 512KB | MAC Address Table Capacity: 8K entries | Jumbo Frames support up to 10KB |
| Layer 2+ Capabilities | 802.1Q Tagged VLAN, Asymmetric VLAN, Voice/Private VLAN, Spanning Tree (STP/RSTP/MSTP), IGMP Snooping v1/v2/v3 |
| Security Controls | 802.1X Port-Based Authentication, RADIUS/TACACS+, Access Control Lists (ACL), IPv4/IPv6 Static Routing |
| Power over Ethernet Budget | 185 Watts total output power budget capability | Support for automatic/manual port wattage classification |
| Cooling Systems & Acoustics | Dual built-in automatic smart cooling fans | Maximum acoustic noise profile: 52 dB(A) |
| Dimensions & Weight | 440 x 250 x 44mm (17.3 x 9.8 x 1.74 in.) | 3.66 kg (8.06 lbs.) |
| Package Contents | TPE-1620WS Switch, Quick Installation Guide, AC Power Cable, Complete Rackmount Bracket Hardware Kit |
