TRENDnet TPE-115GI – Seamlessly Convert Non-PoE Ports to Power-Over-Ethernet
The TRENDnet TPE-115GI Gigabit PoE+ Injector combines electrical power with a high-speed Gigabit network connection to produce a potent Power over Ethernet Plus (PoE+) signal. This device allows you to easily connect a non-PoE Gigabit switch to a remote PoE/PoE+ device up to 100 meters (328 ft.) away using a single standard Ethernet cable.
Eliminate the high cost and clutter of running separate AC power lines to remote locations. Equipped with smart auto-sensing technology, the TPE-115GI automatically recognizes and supplies the exact required wattage—delivering up to 30 Watts to 802.3at PoE+ devices, or 15.4 Watts to legacy 802.3af PoE hardware. It is the perfect, budget-friendly infrastructure solution for deploying TRENDnet IP surveillance cameras, VoIP hardware, and high-performance wireless Access Points (APs).
Key Features
- Full Duplex Gigabit Speeds: Experience blistering fast networking with support for full-duplex throughput up to 2000 Mbps per port.
- Auto-Sensing Intelligence: Intuitively delivers up to 30W to 802.3at PoE+ devices or 15.4W to older 802.3af PoE devices without damaging non-PoE accessories.
- Integrated Power Supply: Built-in internal power converter keeps desktop or wall configurations neat and free of bulky power brick clutter.
- Long-Range Networking: Run data and power safely over standard Cat5e/Cat6 wiring to distances of up to 100 meters (328 feet).
- Hassle-Free Plug-and-Play: Requires zero software installation or management configuration—simply hook it up to your networks and it works.
- Enterprise Safety & Protection: Integrated hardware defenses safeguard your premium network clients with short-circuit and over-current protection.
Official Product Overview Video
Learn more about TRENDnet's specialized Power over Ethernet injector lineup and hardware family functionality:
Technical Specifications
| Specification | Value |
|---|---|
| Model | TPE-115GI |
| Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3af (15.4W), 802.3at (30W) |
| Device Interfaces | 1x Gigabit Data-In Port & 1x Gigabit PoE+ Data-Out Port |
| Data Transfer Rate | Gigabit: 2000 Mbps (Full Duplex mode) |
| PoE Delivery Allocation | Mode A (Pin 1, 2 for power+ and Pin 3, 6 for power-) |
| Max. Power Output | Up to 30 Watts |
| Power Input | 100-240V AC, 50/60Hz, 0.8A max (Internal Power Supply) |
| Power Consumption | Max. 1.03W (Standby with no powered client device attached) |
| LED Indicators | System Status / Power & PoE Link Confirmation |
| Special Mounting | Integrated Wall-Mountable slots |
| Operating Temp | 0°C to 40°C (32°F to 104°F) |
| Dimensions & Weight | 155 x 57 x 33 mm (6.1 x 2.3 x 1.3 in.) / 188 g (6.64 oz.) |
| Certifications | CE, FCC Compliant |
