Description
Achieve lightning-fast, high-capacity enterprise networking over long distances with the TP-Link TL-SM5110-LR 10GBase-LR SFP+ LC Transceiver. Engineered specifically to meet the demanding infrastructure requirements of modern data centers, remote office hubs, and campus backbones, this high-performance 1310nm single-mode transceiver extends 10Gbps Ethernet connectivity seamlessly, ensuring low-latency and maximum throughput for virtualized workloads and campus-wide expansion.
Key Features
- Blazing-Fast 10G Throughput: Unleash full 10Gbps bandwidth capacity to support modern virtualized environments, hyper-converged nodes, and high-capacity long-distance enterprise aggregation.
- Long-Range Single-Mode Support: Extends full-duplex 10G Ethernet connections up to 10 kilometers (6.2 miles) using high-quality 9/125μm single-mode fiber (SMF) cabling.
- Hot-Pluggable Design: Maintain maximum network uptime. Seamlessly install or replace this compact transceiver module on-the-fly without shutting down your enterprise switches, routers, or server hardware.
- Digital Diagnostic Monitoring (DDM): Supports SFF-8472 compliant DDM functionality to track crucial physical metrics in real time—including operating temperature, transmit power, receive optical power, and supply voltage—simplifying preventive maintenance.
- Universal SFP+ Compatibility: Complies with standard 10G SFP+ Multi-Source Agreement (SFP+ MSA) specifications. Works perfectly with TP-Link JetStream and Omada switches (such as the TL-SG3428X and TL-SG3428XMP) as well as other industry-standard 10G optical hardware.
- Low EMI Construction: Engineered with a premium, fully enclosed metallic chassis that shields against electromagnetic interference (EMI) to ensure stable signal transmissions in crowded network racks.
Technical Specifications
| Specification Type | Details |
|---|---|
| Product Code | TL-SM5110-LR |
| Standards and Protocols | IEEE 802.3ae, TCP/IP, SFF-8472 |
| Form Factor | SFP+ (Hot-Pluggable) |
| Port / Connector Type | LC Duplex |
| Fiber Type | 9/125μm Single-Mode |
| Wavelength | 1310 nm |
| Max Cable Distance | Up to 10 km (6.2 miles) |
| Data Rate | 10 Gbps |
| Digital Diagnostic Monitoring (DDM) | Yes (SFF-8472 compliant) |
| Power Supply | 3.3V (provided by host switch SFP+ slot) |
| Dimensions (W x D x H) | 2.2 × 0.5 × 0.4 inches (56.7 × 13.9 × 10.35 mm) |
| Certifications | FCC, CE, RoHS |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
