Description
Empower your business network with reliable performance and smart management using the TP-Link TL-SG2016P JetStream 16-Port Gigabit Smart Switch. Equipped with 8 PoE+ ports supporting up to 120W total power budget, this switch easily powers IP cameras, access points, and VoIP phones while delivering lightning-fast gigabit connectivity. Backed by integrated Omada SDN cloud management, it provides centralized control, robust security features, and seamless scalability for modern enterprise and surveillance networks.
Key Features
- 8 PoE+ Gigabit Ports: Features 8 PoE+ compliant ports conforming to 802.3af/at standards with a total power supply of up to 120W.
- Full Gigabit Speed: 16 gigabit ports provide high-speed connections for data-heavy applications and smooth multi-device transmissions.
- Omada SDN Integration: Supports centralized cloud management, Zero-Touch Provisioning (ZTP), and intelligent monitoring via the Omada app or web UI.
- Advanced Security Strategy: Includes IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, and 802.1X authentication.
- Optimized Voice & Video Applications: L2/L3/L4 QoS and IGMP snooping ensure smooth performance for latency-sensitive voice and video streams.
- Standalone Management: Versatile management modes via Web, CLI, SNMP, and RMON for flexible network setups.
Technical Specifications
| Feature | Specification |
|---|---|
| Product Model | TP-Link TL-SG2016P |
| Interface | 16 x 10/100/1000 Mbps RJ45 Ports (Ports 1–8 support 802.3af/at PoE+) |
| PoE Budget | 120W total PoE power budget |
| Switching Capacity | 32 Gbps |
| Packet Forwarding Rate | 23.8 Mpps |
| Management Software | Omada SDN Controller (Cloud-based, Hardware, Software) |
| Enclosure Type | Steel Desktop / Wall-mounting case (Fanless design) |
| Dimensions & Weight | 209 mm x 126 mm x 26 mm | Desktop / Wall-Mountable |
