Description
Expand your business network capacity effortlessly with the TP-Link TL-SF1024D 24-Port Fast Ethernet Switch. This high-performance, unmanaged rackmount/desktop switch provides an easy, cost-effective way to upgrade your legacy network infrastructure to 10/100Mbps speeds. Featuring a rugged metal housing and energy-efficient architecture, it delivers reliable wire-speed data transferring for small to medium business environments.
Key Features & Highlights
- 24 Fast Ethernet Ports: Outfitted with 24 x 10/100Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX, eliminating the need for crossover cables.
- Plug and Play Setup: An unmanaged, hassle-free design means no configuration is required. Simply plug in your devices for an instant, seamless network extension.
- Green Ethernet Technology: Innovative energy-saving features automatically adjust power consumption according to link status and cable length, reducing your network's carbon footprint.
- Reliable Data Flow: Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode to prevent traffic congestion and dropouts.
-
Durable & Flexible Design: Protected by a rugged, fanless metal enclosure for completely silent operation, suitable for standard 13-inch rackmount installations or convenient desktop placement.
Technical Specifications
Specification Details Brand / Model TP-Link TL-SF1024D Standards and Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3x Interface 24× 10/100Mbps RJ45 Ports (Auto Negotiation, Auto MDI/MDIX) Network Media 10BASE-T / 100BASE-TX: UTP category 3, 4, 5 cable (maximum 100m) Switching Capacity 4.8 Gbps Packet Forwarding Rate 3.57 Mpps MAC Address Table 8K Advanced Features Green Technology, 802.3X Flow Control Transfer Method Store-and-Forward Fan Quantity Fanless (Silent Operation) Power Supply Internal 100-240VAC, 50/60Hz Max Power Consumption 3.2W Mounting Type Desktop or 13-inch Rack Mountable (Rackmount kit included) Dimensions 11.6 × 7.1 × 1.7 in. (294 × 180 × 44 mm)
