Description
TP-Link Omada OC200 Cloud SDN Hardware Controller — Professional Centralized Management
Take complete control over your enterprise infrastructure with the TP-Link Omada OC200 Hardware Controller. Built specifically to provide hospitality, education, retail, and corporate environments with centralized network tracking, this dedicated hardware device hosts the entire Omada Software Defined Networking (SDN) platform without needing a dedicated PC or server running 24/7. Achieve complete hybrid-cloud access, advanced system security, and easy multi-site logistics from an ultra-reliable, compact appliance.
Key Performance Features
- Centralized On-Premises Management: Monitor, configure, and provision up to 100+ Omada access points, JetStream switches, and SafeStream VPN gateways simultaneously from a unified management dashboard.
- Free Cloud Access with No Subscriptions: Manage your network on the go via the web UI or the intuitive Omada App from anywhere in the world, with zero ongoing platform licensing costs or maintenance fees.
- Enterprise Hardware Architecture: Equipped with an industry-leading processor, a durable metal shell housing, a USB 2.0 port for automated scheduled data backups, and two fast Ethernet tracking links.
- Flexible Power Delivery: Eliminates clutter by supporting standard 802.3af/at Power-over-Ethernet (PoE), or power it directly using a standard Micro USB (DC 5V/Minimum 1A) line for hassle-free setups.
- Advanced Client & Guest Optimization: Boost your enterprise branding and guest isolation using a customizable Captive Portal layout incorporating Facebook Wi-Fi, SMS verification, and voucher login systems.
Step-by-Step Configuration Showcase
Watch this official step-by-step setup walkthrough to see how easy it is to deploy, provision, and connect network access points using a web browser interface with the Omada OC200:
Technical Specifications
| Feature | Specification Details |
|---|---|
| Product Model | Omada OC200 Hardware Controller |
| Physical Interfaces | 2x 10/100 Mbps Ethernet Ports, 1x USB 2.0 Port (for database configuration storage backups), 1x Micro USB Port |
| Power Supply Options | 802.3af/at standard Power-over-Ethernet (PoE) OR Micro USB (DC 5V / Minimum 1A) |
| Scalable Management | Up to 100+ Omada Access Points, JetStream Switches, and SafeStream Gateways |
| Enterprise Features | L3 Management, Multi-Site Management, Automated Backup, Real-time Topology & Traffic Graphs, Firmware Batch Upgrades |
| Authentication Controls | Captive Portal Portal Authentication (SMS, Voucher, Local User, Radius, Facebook WiFi) |
| Mobile Management Application | Supports Omada App (Available on iOS and Android platforms) |
| Enclosure Architecture | Durable Metal Casing with Kensington Security Lock Slot |
| System Requirements | Microsoft Windows 10, 8, 7, Server variants, Linux, or macOS for controller browser accessibility |
| Dimensions (W x D x H) | 3.9 x 3.9 x 1.0 inches (100 x 98 x 25 mm) |
