Description
- Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
- Basic Function
- Auto-negotiation of Half-Duplex / Full-Duplex transfer mode
- Extends fiber distance up to 1,800 feet (550m) using 50/125um fiber
- Extends fiber distance up to 720 feet (220m) using 62.5/125um fiber
- Ports
- 1 x 1000M dual SC/UPC port
- 1 x 10/100/1000M RJ45 port (Auto MDI/MDIX)
- Wave Length: 850nm
- Network Media 1000BASE-SX: Multi-mode Fiber
- Network Media 1000BASE-T
- UTP category 5, 5e cable (maximum 100m)
- EIA/TIA-568 100Ω STP (maximum 100m)
- LED Indicators: PWR, Link/Act
- Dimensions (W*D*H)
- 3.7 × 2.9 × 1.1 in.
- (95 × 73 × 27 mm)
- Power Supply: External Power Adapter
- Max Power Consumption: 1.66W
- Safety & Emission: FCC, CE, RoHS
- Package Contents
- Media Converter MC200CM
- Power Adapter
- Installation Guide
- Environment
- Operating Temperature: 0℃~40℃ (32℉~104℉)
- Storage Temperature: -40℃~70℃ (-40℉~158℉)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
