Description
Engineered for extreme outdoor conditions, the TP-Link CPE610 5GHz 300Mbps 23dBi Outdoor CPE is built to deliver cost-effective performance for long-distance wireless networking. Featuring a high-gain 23dBi directional Cassegrain antenna, dedicated metal reflector, and advanced MAXtream TDMA technology, it provides exceptional beam directivity, minimized latency, and high throughput over multi-kilometer ranges—making it an ideal choice for point-to-point and point-to-multipoint applications.
Key Features
- Long-Range Transmission: Equipped with a 23dBi high-gain 2x2 MIMO directional Cassegrain antenna and metal reflector for exceptional connectivity spanning over 30 km.
- Pharos MAXtream TDMA Technology: Enhances throughput, network capacity, and latency performance, perfect for PTMP applications.
- Weatherproof Structural Design: IP65-rated weatherproof enclosure built to withstand harsh winds, rain, and extreme climates.
- Robust Protection: Features 15kV ESD and 6kV lightning protection to safeguard against electrical surges and ensure uninterrupted reliability.
- Fast & Easy Assembly: Innovative snap-lock parts allow rapid assembly, complemented by flexible three-axis alignment pole-mounting kits.
- Centralized Management: Supported by Pharos Control software, giving network administrators an intuitive tool for system management.
Technical Specifications
| Specification Category | Details |
|---|---|
| Processor | Qualcomm 560MHz CPU, MIPS 74Kc |
| Memory | 64MB DDR2 RAM, 8MB Flash |
| Interface | 1× 10/100Mbps Shielded Ethernet Port (LAN/POE) |
| Antenna Gain | 23dBi |
| Wireless Speeds | Up to 300Mbps (40MHz, Dynamic) |
| Operating Frequency | 5.15 ~ 5.85GHz |
| Power Supply | Passive Power over Ethernet via LAN (+4,5pins; -7,8pins); Voltage range: 16-27VDC |
| Enclosure Rating | IP65 Weatherproof, 6KV Lightning / 15KV ESD Protection |
| Dimensions (W x D x H) | 14.1 × 11.0 × 8.0 in. (360 × 280 × 207 mm - with mounts) |
