Teltonika RUT200 Industrial Cellular Router

Teltonika RUT200 Industrial Cellular Router

• Brand: Teltonika

• Model: RUT200

• RUT200 is a compact industrial cellular router that provides reliable, mission-critical connectivity in rigorous conditions common in industries like automation, transportation, and manufacturing. This model is equipped with 4G LTE, Wi-Fi, and two Ethernet ports, making it ideal for quickly setting up primary and backup connectivity with remote management capabilities.

• Mobile
  Mobile module: 4G LTE Cat 4 up to 150 DL/50 UL Mbps; 3G up to 21 DL/5.76 UL Mbps; 2G up to 236.8 DL/236.8 UL kbps
  3GPP Release: Release 9
  Status: IMSI, ICCID, operator, operator state, data connection state, network type, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and
• MNC
  SMS: SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
  USSD: Supports sending and reading Unstructured Supplementary Service Data messages

• Black/White list: Operator black/white list (by country or separate operators)
  Multiple PDN: Possibility to use different PDNs for multiple network access and services

• Band management: Band lock, Used band status display

• SIM PIN code management: SIM PIN code management enables setting, changing, or disabling the SIM card's PIN

• APN: Auto APN

• Bridge: Direct connection (bridge) between mobile ISP and device on LAN

• Passthrough: Router assigns its mobile WAN IP address to another device on LAN

• Wireless

• Wireless mode: 802.11b/g/n (Wi-Fi 4), Access Point (AP), Station (STA)

• Wi-Fi security: WPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-
• SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates, disable auto-reconnect, 802.11w Protected
• Management Frames (PMF)
  SSID/ESSID: SSID stealth mode and access control based on MAC address
  Wi-Fi users: Up to 50 simultaneous connections
  Wireless Connectivity Features: Fast roaming (802.11r), Relayd, BSS transition management (802.11v), radio resource measurement (802.11k)

• Wireless MAC filter: Allowlist, blocklist

• Wireless QR code generator: Once scanned, a user will automatically enter your network without needing to input login information

• TravelMate: Forward Wi-Fi hotspot landing page to a subsequent connected device

• Network

• Routing: Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing

• Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN
  VoIP passthrough support: H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets

• Connection monitoring: Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection

• Firewall: Port forward, traffic rules, custom rules, TTL target customisation

• Firewall status page: View all your Firewall statistics, rules, and rule counters

• Ports management: View device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so on
  Network topology: Visual representation of your network, showing which devices are connected to which other devices

• DHCP: Static and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcards

• DATA TO SERVER

• Protocol: HTTP(S), MQTT, Azure MQTT, Kinesis

• Data to server: Extract parameters from multiple sources and different protocols, and send them all to a single server; Custom LUA scripting, allowing scripts to utilize the router's Data to server feature
