Synology RackStation RS2423RP+II 12-Bay 2U Rackmount NAS Enclosure
Consolidate data storage, endpoint backups, and collaborative workloads with the Synology RackStation RS2423RP+II 12-Bay Rackmount NAS Enclosure. Designed for small-to-medium businesses and branch offices, this powerful 2U server features an AMD Ryzen™ quad-core processor, high-speed 10GbE networking, and dual redundant power supplies to deliver performance exceeding 3,500 MB/s sequential read throughput.
Key Features
- High-Performance Processing: Powered by an AMD Ryzen™ quad-core CPU and 8GB DDR4 ECC memory (expandable up to 32GB) to safeguard against data corruption.
- Flexible 12-Bay Storage: Supports 3.5" and 2.5" SATA HDDs and SSDs. Expand up to 24 drive bays (up to 432TB raw storage) by attaching a Synology RX1223RP expansion unit.
- Integrated 10GbE & Expansion: Features one built-in 10GbE RJ-45 port and two 1GbE RJ-45 ports. Includes a PCIe 3.0 slot to easily install 10/25GbE network interface cards or M.2 NVMe SSD cache adapters.
- Dual Redundant Power Supplies: Equipped with dual hot-swappable 550W power supplies to prevent downtime and protect continuous business operations.
- License-Free Business Continuity: Pre-loaded with Synology Active Backup Suite, Snapshot Replication, and Hyper Backup for complete protection across VMs, Windows, Linux, and cloud workloads.
- Virtualization Ready: Certified for VMware® vSphere™, Microsoft® Hyper-V®, Citrix® XenServer™, and OpenStack® environments.
Technical Specifications
| Brand | Synology |
|---|---|
| Model | RackStation RS2423RP+II |
| Form Factor | 2U Rackmount |
| CPU Model | AMD Ryzen V1780B (4-core 3.35 GHz, Turbo up to 3.6 GHz) |
| System Memory | 8GB DDR4 ECC UDIMM (Expandable up to 32GB) |
| Drive Bays | 12x 3.5" or 2.5" SATA HDD/SSD (Hot-swappable) |
| Maximum Bays with Expansion | 24 (via RX1223RP expansion unit) |
| Supported RAID Types | Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
| RJ-45 LAN Ports | 1x 10GbE RJ-45, 2x 1GbE RJ-45 (Supports Link Aggregation / Failover) |
| PCIe Expansion Slot | 1x Gen3 x8 slot (x8 link) |
| External Ports | 2x USB 3.2 Gen 1, 1x Mini-SAS HD expansion port |
| Power Supply Unit | Dual 550W Redundant Power Supplies (100V to 240V AC) |
| System Fans | 3x (60mm x 60mm) |
| Operating System | Synology DiskStation Manager (DSM) |
| Dimensions (H x W x D) | 88 mm x 482 mm x 578 mm (3.46 in x 18.98 in x 22.75 in) |
| Weight | 11.9 kg (26.2 lbs) |
| Warranty | 3 Years |
