Upgrade your surveillance setup with the Ruijie Reyee RG-ES126FGS-LP 24-Port Unmanaged PoE Switch. Engineered engineered specifically for high-reliability IP CCTV networks across Myanmar, this cloud-visible rackmount switch features 24 Fast Ethernet PoE+ ports and 2 Gigabit uplink combo ports. Delivering a stable 180W power budget alongside hardware-level smart auto-recovery, it is the absolute go-to choice for offices, warehouses, retail hubs, and hotels in Yangon and Mandalay seeking uninterrupted security feeds.
Ruijie Reyee RG-ES126FGS-LP: The Ultimate Smart CCTV Unmanaged PoE Switch
The Ruijie Reyee RG-ES126FGS-LP breaks the mold of traditional networking hardware. While operating as a zero-configuration, plug-and-play unmanaged switch, it features a unique "Cloud-Visible" architecture. This allows system integrators and business owners to monitor topology and status metrics remotely via the free Ruijie Cloud platform. Encased in a heavy-duty steel rackmount chassis, this 180W Low-Power (LP) variant optimizes power efficiency while providing full 30W PoE+ streams to high-definition IP cameras, access points, and VoIP hardware.
Key Features & Enterprise-Grade Network Benefits
- 24 PoE+ Ports + Dual Gigabit Uplinks: Offers 24 10/100 Mbps ports with IEEE 802.3af/at standard compliance, backed by 1 dedicated Gigabit RJ45 port and 1 Gigabit SFP/RJ45 combo port for lightning-fast backbone fiber or copper connectivity.
- Intelligent PoE Watchdog (Auto-Recovery): Acts as a virtual multi-site network technician. The switch automatically detects frozen IP cameras or unresponsive endpoints and auto-restarts them by cycling the specific port’s power supply.
- Hardware DIP Switch Extended Mode (200m+): Switch to "Extend Mode" via a physical front toggle to drop the data rate of ports 1 to 8 to 10 Mbps while boosting transmission distance up to an incredible 200 meters over standard Cat5e or Cat6 cabling.
- One-Click VLAN Isolation & Flow Control: Instant port-isolation mode blocks communication between ports 1 to 24 to prevent malicious lateral broadcast storms and network sniffing, safeguarding your sensitive security data.
- Industrial-Grade Built-in Surge Safety: Outfitted with ±4kV common mode service port surge protection and ±6kV power connector protection to withstand volatile voltage grids and monsoon lightning strikes.
- Free App Cloud Visibility: Get the maintenance advantages of a managed switch without the high cost. View port load, troubleshoot remotely, and receive instant camera-offline notifications via the free Ruijie Reyee app (requires at least one managed device on the wider LAN).
Comprehensive Technical Specifications
Review the explicit hardware layout and performance threshold metrics for the RG-ES126FGS-LP switch below:
| Parameter | Technical Specification Details |
|---|---|
| Model Name | RG-ES126FGS-LP |
| Switch Class Type | Unmanaged (Ruijie Cloud-Visible Platform Supported) |
| Total Hardware Ports | 26 Ports Total |
| Port Breakdown | 24 x 10/100BASE-T PoE+ Ports | 2 x 10/100/1000BASE-T Ports | 1 x Combo SFP Port |
| Switching Capacity | 8.8 Gbps |
| Packet Forwarding Rate | 6.5 Mpps |
| MAC Address Table | 8,000 Entries (8K) |
| PoE Standard Formats | IEEE 802.3at (PoE+) / IEEE 802.3af (PoE) |
| Total Allocated PoE Budget | 180 W |
| Maximum Per-Port PoE Output | Up to 30 W per Port |
| DIP Switch Modes Allowed | Default Mode, Extend Mode (200m range for ports 1-8), Isolation Mode (VLAN) |
| Surge Protection Threshold | Service ports: ±4 kV (Common Mode) | Power supply: ±6 kV (Common/Differential) |
| Cooling System Setup | 1 x Built-in fixed speed-controlled fan (Front-to-Rear Airflow) |
| Chassis Architecture | High-durability Industrial Galvanized Steel Case |
| Power Input Requirements | 100 V AC to 240 V AC, 50 Hz to 60 Hz | Max Draw: 200 W (PoE Full Load) |
| MTBF Standard Reliability | > 200,000 Hours |
| Dimensions & Chassis Format | 440 mm x 214.9 mm x 44 mm (Standard 1U 19-inch Rackmount) |
| Net Weight | 2.64 kg (Device only) | 3.20 kg (With complete retail packaging setup) |
