Description
Elevate your business meetings and classroom lessons with the Epson EB-E24 XGA 3LCD Projector. Built for high impact and seamless operation, this high-performance projector delivers vibrant, crystal-clear visual presentations even in well-lit rooms. With 3,600 lumens of equal color and white brightness, long-lasting lamp life, and flexible connectivity options, the EB-E24 offers exceptional versatility and a low total cost of ownership.
Key Features & Highlights
- Bright, Vivid Visuals (3LCD Technology): Powered by Epson’s signature 3-chip 3LCD technology, experience up to 3,600 lumens of both color and white brightness for crisp, accurate image display.
- Detailed XGA Resolution: High-definition XGA (1024 x 768) resolution delivers sharp text and clear graphics, perfect for detailed spreadsheets, presentations, and educational content.
- Ultra-Long Lamp Life: Reduce maintenance hassle and operational costs with an extended lamp life of up to 12,000 hours in ECO mode (6,000 hours in Normal mode).
- Scalable Screen Size up to 350 Inches: Project massive images ranging from 30 inches up to 350 inches diagonal, ensuring everyone in the room has a clear view.
- Split-Screen Capability: Display content from two separate source devices side-by-side simultaneously for more interactive presentations and collaborative working.
- Flexible Keystone Correction: Quick setup with ±30° vertical and horizontal keystone correction to easily align images without distorting proportions.
- Versatile Digital & Legacy Inputs: HDMI Type-A, dual VGA (D-Sub 15pin) inputs, RCA, stereo mini audio, and RS-232C control ensure seamless compatibility with modern and older hardware.
- Built-in 5W Speaker: Integrated monaural speaker provides clear audio output out of the box without requiring external sound systems.
- EB-E24 BUSINESS PROJECTOR ( 3600 Lum, XGA)
Technical Specifications
| Specification Category | Details |
|---|---|
| Projection System | 3LCD Technology (RGB liquid crystal shutter) |
| Native Resolution | XGA (1024 x 768 pixels, 4:3 Aspect Ratio) |
| Color & White Brightness | 3,600 Lumens (Normal) / 2,100 Lumens (Eco) |
| Contrast Ratio | 15,000:1 |
| Light Source Type | 210 W UHE Lamp |
| Lamp Life | Up to 6,000 hours (Normal) / 12,000 hours (Eco) |
| Screen Size (Projected) | 30" to 350" [0.87m to 10.34m throw distance] |
| Keystone Correction | Vertical: ±30° / Horizontal: ±30° |
| Digital Connectivity | 1 x HDMI Type A (HDCP 1.4) |
| Analog Connectivity | 2 x D-Sub 15pin (VGA In), 1 x D-Sub 15pin (VGA Out), 1 x RCA Composite Video |
| Audio I/O | 2 x Stereo Mini In, 1 x 2RCA (Red/White) In, 1 x Stereo Mini Out |
| Control Interface | 1 x RS-232C (D-Sub 9pin), 1 x USB Type-B (Firmware & Service) |
| Built-in Audio | 5W Monaural Speaker |
| Power Consumption | 332W (Normal) / 231W (Extended/Eco) / 0.3W (Standby) |
| Fan Noise Level | 37 dB (Normal) / 28 dB (Eco) |
| Dimensions (Excl. Feet) | 302 mm x 249 mm x 87 mm (W x D x H) |
| Weight | Approx. 2.7 kg |
