Dragon Power DG-MPS-6048 6kVA / 4800W Combined Pure Sine Wave Hybrid Inverter
Achieve bulletproof, industrial-grade power independence with the heavy-duty Dragon Power DG-MPS-6048 Combined Hybrid Inverter. Engineered specifically to serve as the main defense line against prolonged rolling blackouts, grid dropouts, and daily load shedding across Myanmar, this continuous 4800-watt power center consolidates a pure sine wave power inverter, an intelligent multi-stage AC utility battery charger, and a dedicated solar power management module into a singular, high-strength wall-mounted chassis.
Operating on a low-loss 48VDC Battery Architecture, the DG-MPS-6048 is highly optimized for substantial residential layouts, multi-room offices, servers, clinical cold storage, and retail operations. It produces a premium Pure Sine Wave Output that mirrors a clean municipal utility grid, ensuring that heavy inductive loads, air conditioning units, water pumps, refrigerators, and high-end IT systems run coolly, silently, and completely free from the harmonic distortion or internal buzzing that damages electronics on modified wave alternatives.
Key Features & Engineering Highlights
- Substantial 4800W Continuous Pure Sine Wave Delivery: Confidently powers high-surge inductive loads, desktop workstations, surveillance grids, and high-wattage home appliances simultaneously.
- Integrated 60A Solar Charge Controller: The built-in heavy-duty charging management framework tracks and paths high-amperage photovoltaic currents directly from your solar panels to quickly replenish depleted battery banks.
- 48VDC Low-Loss Power Infrastructure: Utilizes a 48V configuration (four 12V deep-cycle batteries in series or a 48V Lithium module array) to lower operational DC currents, dramatically decreasing line cable heat generation and increasing overall system efficiency.
- Smart Energy Priority Automation: Programmable logic parameters allow you to prioritize input paths via the central LCD screen. Easily select between Solar First, Utility Grid First, or Battery Backup First to minimize fuel or electricity expenses.
- High-Speed UPS Transfer Switching: Automatically switches power sources within milliseconds during sudden blackouts, preventing critical computer networks from resetting and keeping communication grids online.
- Advanced Electronic Protection Array: Equipped with premium industrial protection circuits covering Overloads, Short Circuits, High Temperatures, Battery Overcharging, and Deep Discharge Degradation.
Technical Specifications Table
Verify the precise electrical boundaries, charge configurations, and physical footprints for the Dragon Power DG-MPS-6048 system:
| Specification Parameter | Official Factory Performance Details |
|---|---|
| Brand & Model Name | Dragon Power DG-MPS-6048 (Combined Series) |
| Apparent Power System Rating | 6000 VA / 6 kVA |
| Continuous Active Power Capacity | 4800 Watts Steady-State Load Handling |
| Output Waveform Configuration | Pure Sine Wave (Clean Utility Line Simulation) |
| Nominal DC System Input Voltage | 48 VDC (Requires 4x 12V Batteries in Series or 48V Lithium Storage Module) |
| AC Input/Output Operating Window | Input: 230VAC Standard | Output: 230VAC ± 5% Single Phase (50Hz/60Hz Self-Sensing) |
| Built-in Solar Charger Controller | 60 Amp High-Amperage Solar Power Management Framework |
| Maximum Solar Array Input Voltage (VOC) | 100 VDC Maximum Absolute Open-Circuit Open Voltage Threshold |
| Maximum Utility AC Charging Current | 15A / 30A Selectable Constant Charging Profiles |
| UPS Transfer Switch Speed | ≤ 10ms Typical (For Computers) | 20ms Max (For General Electrical Appliances) |
| Physical Scale Structural Design | Heavy-Duty Wall-Mounted Space Architecture Layout |
| Local Technical Service Protection | 5-Years Local Authorized Distributor Warranty Support Plan |
