High-Density Web Smart Managed Switch for Scalable Enterprise Environments
The D-Link DGS-1210-28 is a robust, high-performance 28-Port Web Smart Managed Gigabit Switch explicitly developed to form the reliable central core or distribution backbone of medium businesses, educational campuses, and corporate networks. Furnished with 24 dedicated 10/100/1000 Mbps RJ45 ports and 4 dedicated Gigabit SFP fiber optic uplink ports, this network powerhouse supports seamless structural expansions over long distances without causing local bandwidth congestion. Providing advanced Layer 2 management tools, static routing, and absolute silent operation at half-load, it is the premier choice for professional IT deployment across Yangon, Mandalay, and growing digital sectors throughout Myanmar.
Key Performance Features & Enterprise Capabilities
- Advanced L2 Features with Layer 3 Static Routing: Incorporates IGMP Snooping, Port Mirroring, Spanning Tree Protocols (STP/RSTP/MSTP), and Link Aggregation (LACP), plus corporate Layer 3 Static Routing to allow seamless data flow directly across internal VLAN subnets.
- Asymmetric VLAN, Voice, & Auto Surveillance VLAN: Seamlessly segments corporate communications. Automatically isolates and prioritizes mission-critical VoIP phone calls and high-bandwidth IP security camera streams to guarantee stutter-free operations.
- Comprehensive D-Link Safeguard Engine: Protects your office infrastructure against devastating system network crashes caused by intentional malicious attacks, accidental loops, or broad broadcast packet flooding.
- Smart Fan Noise Mitigation: Features specialized internal temperature-tracking smart fans that remain completely powered down under nominal business loads—ensuring noise-free operation within open-plan offices and reception desks.
- Flexible Network Administration Tools: Fully supports an intuitive Web-based Graphical User Interface (GUI), the streamlined D-Link Network Assistant (DNA) utility, industrial-standard SNMP v1/v2c/v3 profiles, and compact Command Line Interface (CLI) configurations via Telnet.
D-Link DGS-1210-28 Complete Engineering Specifications
Verify advanced architectural switching throughput, electrical ratings, and regulatory network dimensions prior to local system rack mounting:
| Hardware Parameters | Official Factory Specification Matrix |
|---|---|
| Product Model Number | DGS-1210-28 (Smart Managed Series) |
| Total Ports Available | 28 Active Interfaces |
| Gigabit Copper RJ45 Ports | 24 x 10/100/1000 Mbps Base-T Ports |
| Optical SFP Uplink Interface | 4 x 1000 Mbps Dedicated SFP Fiber Optic Ports |
| Switching Fabric Capacity | 56 Gbps (Non-blocking Backplane Fabric Bandwidth) |
| Maximum Packet Forwarding Rate | 41.67 Mpps (Million Packets Per Second) |
| MAC Address Table Size | 16,000 Entries (Supports Automatic Learning & Aging) |
| Packet Buffer Architecture | 1.5 MB Integrated Dynamic Memory Buffer |
| Layer 3 Static Routing Capabilities | Max 124 IPv4 Routes / Max 50 IPv6 Routes |
| Power Supply Input | Internal Universal Supply: 100 to 240 V AC, 50/60 Hz |
| Maximum Power Dissipation | 15.22 Watts (Standby: 5.01 Watts) |
| Cooling & Acoustics Architecture | 1 x Smart Cooling Fan | Acoustic Rating: 21.6 dBA up to max 42.9 dBA |
| VLAN Implementation Array | 802.1Q tagged VLAN, Auto Surveillance VLAN 2.0, Auto Voice VLAN, Port-based VLAN (Up to 4,094 VIDs) |
| Quality of Service (QoS) Layer | 802.1p Quality of Service, 8 Priority Queues per port, Strict/WRR Scheduling options |
| Enterprise Access Cybersecurity | IP-MAC-Port Binding (Smart Binding), 802.1X Port-based Authentication, Access Control Lists (ACL), RADIUS/TACACS+ Integration |
| Chassis Form Factor Dimensions | 440 mm x 140 mm x 44 mm (Standard 19-Inch Width, 1U Height Rackmount brackets included) |
| Unit Net Weight | 2.06 kg (4.54 lbs) |
| Operating Temperature Limits | Operating: -5 to 50 °C | Storage Environment: -20 to 70 °C |
| System Mean Time Between Failure (MTBF) | 1,082,534 Hours of stable, continuous lifetime rating |
| Regulatory & Green Certifications | CE Class A, FCC Class A, VCCI Class A, cUL, CE (LVD), Energy Efficient Ethernet (IEEE 802.3az) |
