Incorporate elite data resilience and wire-speed scalability into your corporate backend with the enterprise-grade Cisco SG550X-24-K9-UK 24-Port Gigabit Stackable Managed Switch. Engineered specifically for complex data environments, mid-market enterprise server rooms, and expanding distribution cores across Myanmar, this advanced Layer 3 managed device breaks standard network speed limits by offering four dedicated 10-Gigabit Ethernet uplink choices. Whether deploying ultra-reliable stack setups across high-rise head offices in Yangon, linking warehouse branches in Mandalay, or building secure government data grids in Naypyidaw, safeguard your organizational uptime with premium Cisco engineering backed by certified warranty protection solutions.
Key Features of the Cisco SG550X-24-K9-UK Stackable Switch
- 24 Gigabit Access Ports + 10G Core Uplinks: Built with 24 x 10/100/1000Mbps RJ45 baseline access ports working alongside 2 x 10-Gigabit copper/SFP+ combo ports and 2 x dedicated 10-Gigabit SFP+ fiber ports to securely drive data directly to your core server pools.
- Resilient True Stacking Scalability: Connect and master up to 8 independent individual units as a single physical ecosystem with uniform management control. Configure, monitor, and troubleshoot up to 400 total data channels simultaneously using a single unified IP address.
- Advanced Line-Rate Layer 3 Traffic Routing: Offload internal operational routing overhead from your core office routers. Runs dedicated hardware-based static IP routing, Dynamic VRRP configuration pathways, policy-based routing (PBR), and RIPv2 structures to maximize overall system bandwidth.
- Comprehensive Enterprise Security Defenses: Defend against local data leaks and network intrusion strategies with advanced Access Control Lists (ACLs), 802.1X port authentication, Guest VLAN segmentation, Dynamic ARP Inspection, IP Source Guard, and DHCP Snooping protections.
- High-Availability Redundant Fan and Power Design: Features an N+1 preinstalled internal active cooling fan matrix alongside a dedicated external Redundant Power Supply (RPS) plug interface, keeping your network operating smoothly through local grid drops or component issues.
- Next-Generation Smart Network Management: Simplifies network mapping using the embedded Smart Network Application (SNA) graphical system. Includes traditional command line interface (CLI) Textview parameters, full SNMP v3 tooling, and dual-image backup protections for safe firmware updates.
Official Video Guide: High-Performance Stacking Configuration
Review this technical walkthrough directly from the factory channel to understand how the Cisco 550X platform leverages Link Aggregation Groups (LAG) and stacking protocols to build highly resilient network topologies:
Cisco SG550X-24-K9-UK Deep Technical Specifications
| System Parameters | Verified Enterprise Specifications |
|---|---|
| Manufacturer Part Number | SG550X-24-K9-UK |
| Product Series Classification | Cisco 550X Series Stackable Managed Switches |
| Management Capabilities | Full Layer 3 Managed (Static Routing, RIPv2, VRRP, PBR) |
| Base Ethernet Access Ports | 24 x 10/100/1000 Mbps Gigabit Ethernet RJ-45 Ports |
| 10-Gigabit Uplink Interfaces | 2 x 10GBase-T copper / SFP+ fiber combo slots + 2 x dedicated 10G SFP+ slots |
| True Stacking Performance | Up to 8 switch chassis units per physical stack (up to 400 data ports managed as one) |
| Total System Switching Capacity | 128 Gbps Non-Blocking Internal Fabric |
| Packet Forwarding Performance | 95.23 Mpps (Millions of Packets per Second for 64-byte packets) |
| Internal Processor Architecture | 800 MHz Dual-Core Embedded ARM Processing Core |
| Onboard Memory Allocation | 512 MB System CPU RAM | 256 MB Flash System Storage |
| Packet Buffer Allocation | 1.5 Megabytes |
| MAC Address Tracking Limit | 16,000 Unicast MAC Addresses active mapping entries |
| Jumbo Frame Support | Up to 9000 Bytes maximum profile capacity |
| Physical Management Ports | 1 x standard RJ-45 serial console connection + 1 x front-facing USB Type-A storage bay |
| Hardware Hardware Redundancy | Preinstalled internal N+1 active redundant fans + external RPS terminal socket |
| Chassis Unit Layout Dimensions | 440 mm x 257 mm x 44 mm (17.3 in x 10.12 in x 1.73 in) | 1RU Structural Space |
| Net Item Mass | 3.27 kg (7.21 lbs) |
| Main System Power Draw | Internal Auto-Ranging 100V-240V AC, 47-63 Hz | Consumption: 33.5 Watts maximum |
Cisco Enterprise Supply and Logistics Infrastructure in Myanmar
Guaranteed Authentic Cisco Certified Inventory
Protect your enterprise backend layers against the hidden network hazards of gray market hardware imports, unverified region cross-shipping variants, or uncertified hardware builds. We source all SG550X stock paths exclusively via authorized Cisco distribution links. Your device is shipped in its factory-sealed original retail container with untouched security layers and accessories.
Insured Corporate Logistics and Fast Township Shipping
We provide trackable, fully-insured B2B logistics delivery paths direct to your server rooms, corporate premises, or development sites across Yangon, Mandalay, and Naypyidaw, alongside localized township shipping coverage throughout Myanmar.
Flexible Local Banking and Invoicing Options
To match your company's procurement procedures smoothly, we support standard direct company bank-to-bank transfers, corporate invoicing accounts, KBZPay (Kpay), and WaveMoney transaction models.
