Description
Engineered to unleash the full potential of Intel's 14th, 13th, and 12th Generation processors, the ASUS Prime B760M-A WiFi Motherboard combines robust power delivery, comprehensive cooling solutions, and flexible tuning options. Built on a micro-ATX form factor, this motherboard delivers reliable performance and next-gen connectivity—making it the ideal choice for intelligent daily productivity builds and high-performance gaming rigs alike.
Key Features
- Intel LGA1700 Socket: Ready for Intel Core 14th, 13th, and 12th Gen processors, Pentium Gold, and Celeron processors.
- Ultrafast Connectivity: Equipped with onboard Wi-Fi 6 (802.11ax) and Realtek 2.5Gb Ethernet for smooth online gaming and lag-free networking.
- Dual PCIe 4.0 M.2 Slots: Supports up to two M.2 slots running at PCIe 4.0 speeds (up to 64 Gbps) for ultra-quick boot times and application loading.
- Advanced DDR5 Memory Support: Features ASUS Enhanced Memory Profile II (AEMP II) and OptiMem II routing to optimize high-speed DDR5 memory performance.
- Comprehensive Cooling: Includes dedicated VRM heatsinks, a PCH heatsink, hybrid fan headers, and Fan Xpert 2+ utility for intelligent thermal control.
- Aura Sync RGB Customization: Onboard Addressable Gen 2 headers and Aura RGB headers allow you to easily sync lighting across your entire hardware ecosystem.
Technical Specifications
| Brand / Model | ASUS / Prime B760M-A WiFi |
| CPU Socket | LGA1700 (Supports Intel 14th, 13th, & 12th Gen Processors) |
| Chipset | Intel B760 |
| Memory (RAM) | 4 x DIMM, Max. 128GB, DDR5 (Dual-Channel, OptiMem II) |
| Graphics Outputs | 1 x DisplayPort, 2 x HDMI ports |
| Expansion Slots | 1 x PCIe 4.0 x16 slot (SafeSlot Core+), 2 x PCIe 4.0 x16 slots (@x4/x1 modes) |
| Storage Support | 2 x M.2 slots (PCIe 4.0 x4) & 4 x SATA 6Gb/s ports |
| Networking | Wi-Fi 6 (802.11ax), Bluetooth, Realtek 2.5Gb Ethernet |
| Rear USB Ports | Total 6 ports (2 x USB 3.2 Gen 2 Type-A, 4 x USB 2.0) |
| Form Factor | Micro-ATX Form Factor (24.4 cm x 23.4 cm) |
