TP-Link Omada ER707-M2 Multi-Gigabit Multi-WAN VPN Router

Supercharge your business gateway with the TP-Link Omada ER707-M2 Multi-Gigabit Multi-WAN VPN Router. Designed for small-to-medium businesses, enterprise branch offices, and demanding remote sites, this desktop/rackmount router features dual 2.5G ports, up to 6 WAN interfaces for load balancing, hardware-accelerated VPN encryption, and seamless integration into the Omada Software Defined Networking (SDN) platform.

Key Features & Highlights

• Dual 2.5G Multi-Gigabit Ports: Equipped with 1x 2.5G RJ45 WAN port and 1x 2.5G RJ45 WAN/LAN port for high-bandwidth fiber broadband connections.
• Up to 6 WAN Ethernet Ports: Multi-WAN load balancing intelligently distributes data streams across up to 6 WAN ports (2.5G RJ45, Gigabit SFP, and Gigabit RJ45) to maximize link utilization.
• Enterprise-Grade Security & VPN: Supports high-throughput IPsec, PPTP, L2TP, and OpenVPN connections for secure site-to-site and client-to-site remote access.
• Omada SDN Centralized Management: Effortlessly provision, manage, and monitor your entire network setup via cloud access or the free Omada App.
• USB 3.0 Mobile Broadband Backup: Connect a compatible 4G/3G USB modem to provide automatic cellular WAN failover during ISP outages.
• Advanced Firewall & Defense: Integrated DoS defense, IP/MAC/URL filtering, Access Control Lists (ACL), and VLAN routing safeguard internal corporate resources.
• Sturdy Metal Casing: Fanless, compact metal design ensures silent operation and reliable heat dissipation for desktop or shelf installation.

Product Overview

High-Bandwidth Multi-Gigabit Connectivity

As high-speed multi-gigabit internet connections become the enterprise standard, the ER707-M2 meets the demand with two 2.5G RJ45 ports. Eliminate bandwidth bottlenecks between your ISP entry point and your internal Omada switches, unlocking full performance for high-density Wi-Fi 6/6E access points and NAS servers.

Multi-WAN Load Balancing & High Availability

Maximize network uptime with intelligent Multi-WAN capabilities. The ER707-M2 automatically routes traffic based on bandwidth proportion across multiple ISP lines or switches to backup links instantly if an main line connection drops. A USB 3.0 port supports 4G/3G modems to serve as an additional cellular redundancy layer.

Unified Centralized Cloud Management

Manage your router alongside switches and access points within a single pane of glass. The Omada SDN ecosystem provides zero-touch provisioning (ZTP), multi-site management, and real-time network health diagnostics from anywhere via the web console or mobile app with zero license fees.

Technical Specifications

Hardware Interfaces	• 1x 2.5G RJ45 WAN Port • 1x 2.5G RJ45 WAN/LAN Port • 1x Gigabit SFP WAN/LAN Port • 4x Gigabit RJ45 WAN/LAN Ports • 1x USB 3.0 Port (4G Modem / Storage)
WAN Port Configurations	Up to 6 WAN Ports simultaneously
Flash / Memory	128 MB SPI NOR + 4 GB eMMC / 1 GB DDR4 RAM
Concurrent Sessions	500,000 Concurrent Connections
VPN Protocols	IPsec, PPTP, L2TP, OpenVPN, WireGuard
IPsec VPN Throughput	Up to 657 Mbps (100 IPsec Tunnels)
OpenVPN Throughput	Up to 129 Mbps (110 OpenVPN Tunnels)
Firewall Features	SPI Firewall, DoS Defense, IP/MAC/URL Filtering, ACL, VLAN Routing
Power Supply	External 12V / 1.5A DC Adapter
Max Power Consumption	14.2 W
Dimensions (W x D x H)	226 x 131 x 35 mm (8.9 x 5.2 x 1.4 in)
Form Factor	Desktop / Wall-Mount / Fanless Design
