Description
TP-Link EAP613 AX1800 Ceiling Mount WiFi 6 Access Point
- Ultra-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz totals 1775 Mbps Wi-Fi speeds.†
- High-Efficiency WiFi 6: More connected devices can enjoy faster speeds.
- Centralized Cloud Management: Manage the whole network locally or from the cloud via web UI or Omada app.
- Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.§
- Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.§
- PoE+ Powered: Supports DC (adapter is not included), 802.3at PoE+, and Passive PoE for flexible installations.
- Ultra-Slim Design: Φ160 mm × 33.6 mm elegant design brings more agility.
- Secure Guest Network: Along with multiple authentication options (SMS/Voucher, etc.) and abundant wireless security technologies.
- HARDWARE FEATURES
- Interface: 1× Gigabit Ethernet (RJ-45) Port
- Button: Reset
- Power Supply
- 802.3at PoE
- 48 V Passive PoE
- 12 V / 1 A DC (Power Adapter IS NOT included)
- Power Consumption
- 11.0W (For PoE);
- 9.9W (For DC)
- Dimensions ( W x D x H ): V2 and above: 6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm)
- Antenna Type
- Internal Omni Antenna
- 2.4 GHz: 2× 4 dBi
- 5 GHz: 2× 5 dBi
- Mounting
- Ceiling /Wall Mounting (Kits included)
- Junction Box Mounting
- WIRELESS FEATURES
- Coverage: 115㎡(1250 ft²)***
- Concurrent Clients: 250+**
- Wireless Standards: IEEE 802.11ax/ac/n/g/b/a
- Frequency: 2.4 GHz and 5 GHz
- Signal Rate
- 5 GHz: Up to 1201 Mbps
- 2.4 GHz: Up to 574 Mbps
- Wireless Functions
- 1024-QAM
- 4× Longer OFDM Symbol
- OFDMA
- Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
- Enable/Disable Wireless Radio
- Automatic Channel Assignment
- Transmit Power Control (Adjust Transmit Power on dBm)
- QoS(WMM)
- MU-MIMO
- Seamless Roaming §
- Omada Mesh§
- Band Steering
- Load Balance
- Airtime Fairness
- Beamforming
- Rate Limit
- Reboot Schedule
- Wireless Schedule
- Wireless Statistics based on SSID/AP/Client
- Wireless Security
- Captive Portal Authentication§
- Access Control
- Wireless Mac Address Filtering
- Wireless Isolation Between Clients
- SSID to VLAN Mapping
- Rogue AP Detection
- 802.1X Support
- WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
- Transmission Power
- CE:
- <20 dBm(2.4 GHz, EIRP)
- <23 dBm(5 GHz band1/2, EIRP) <25 dBm (5 GHz band3)
- FCC:
- <25 dBm (2.4 GHz)
- <25 dBm (5 GHz)
- MANAGEMENT
- Omada App: Yes
- Centralized Management
- Omada Cloud-Based Controller
- Omada Hardware Controller OC300
- Omada Hardware Controller OC200
- Omada Software Controller
- Cloud Access: Yes, through
- OC300
- OC200
- Omada Software Controller
- Omada Cloud-Based Controller
- Email Alerts: Yes
- LED ON/OFF Control: Yes
- Management MAC Access Control: Yes
- SNMP: v1, v2c, v3
- System Logging Local/Remote Syslog: Local/Remote Syslog
- SSH: Yes
- Web-based Management: HTTP/HTTPS
- L3 Management: Yes
- Multi-site Management: Yes
- Management VLAN: Yes
- Zero-Touch Provisioning: Yes. Requiring the use of Omada Cloud-Based Controller
- OTHERS
- Certification
- CE, FCC, RoHS
- Package Contents
- EAP613
- Ceiling/ Wall Mounting Kits
- Installation Guide
- System Requirements: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
- Environment
- Operating Temperature: 0–40 ℃ (32–104 ℉)
- Storage Temperature: -40–70 ℃ (-40–158 ℉)
- Operating Humidity: 10–90% RH non-condensing
- Storage Humidity: 5–90% RH non-condensing
