Description
- Interface: USB 2.0
- Antenna Type: Omni Directional
- Wireless Standards: IEEE 802.11ac, IEEE 802.11a, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
- Frequency: 5GHz, 2.4GHz
- Signal Rate
-
5GHz
-
11ac: Up to 433Mbps(dynamic)
-
11n: Up to 150Mbps(dynamic)
-
11a: Up to 54Mbps(dynamic)
-
2.4GHz
-
11n: Up to 200Mbps(dynamic)
-
11g: Up to 54Mbps(dynamic)
- 11b: Up to 11Mbps(dynamic)
- Reception Sensitivity
-
5GHz：
-
11a 6Mbps: -90dBm
-
11a 54Mbps: -73dBm
-
11n HT20 MCS0: -89dBm
-
11n HT20 MCS7: -70dBm
-
11n HT40 MCS0: -86dBm
-
11n HT40 MCS7: -67dBm
-
11ac VHT80 MCS0: -82dBm
-
11ac VHT80 MCS9: -56dBm
-
2.4GHz:
-
11b 1Mbps: -96dBm
-
11b 11Mbps: -88dBm
-
11g 6Mbps: -89dBm
-
11g 54Mbps: -74dBm
-
11n HT20 MCS0: -89dBm
-
11n HT20 MCS7: -72dBm
-
11n HT40 MCS0: -86dBm
- 11n HT40 MCS7: -66dBm
- Transmit Power: <20dBm (EIRP)
- Wireless Modes: Ad-Hoc / Infrastructure mode
- Wireless Security: Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, 802.1x
- Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM
- Environment
-
Operating Temperature: 0℃~40℃ (32℉~104℉)
-
Storage Temperature: -40℃~70℃ (-40℉~158℉)
-
Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
