Description
Pre-Order Date : Leadtime : 4 ~ 8 Weeks
MikroTik hAP ax³ (C53UiG+5HPaxD2HPaxD) is our most powerful AX home access point yet, engineered to provide unmatched processing power, cutting-edge Gen 6 wireless speeds, and complete network control for demanding households and offices.
Ultimate Power and Wi-Fi 6 Performance for Your Whole Home
Equipped with a modern quad-core ARM CPU running at 1.8 GHz, 1 GB of RAM, and 128 MB of NAND storage, the hAP ax³ effortlessly handles complex firewall rules, IPsec hardware encryption, WireGuard VPN tunnels, BGP, and advanced routing. Featuring Wi-Fi 6 (802.11ax) technology along with Wave 2 support, enjoy up to 40% higher speeds in the 5 GHz spectrum and up to 90% higher speeds in the 2.4 GHz spectrum.
Key Features
- Next-Gen Wi-Fi 6 (AX1800): Faster speeds, lower latency, and higher client capacity across dual-band, dual-chain wireless.
- Ultra-Fast 2.5 Gigabit Port: Features one ultra-fast 2.5 GbE port with PoE-in/out support alongside four Gigabit Ethernet ports.
- High-Performance Processing: Powered by an IPq-6010 quad-core 1.8 GHz ARM 64-bit processor and 1 GB RAM.
- Potent External Antennas: High-gain external antennas (up to 5.5 dBi on 5 GHz) eliminate the need for extra Wi-Fi boosters.
- USB 3.0 Support: Integrated USB 3.0 port for external storage network file sharing or connecting an additional LTE/5G modem.
- Powered by RouterOS v7: Advanced routing, zero subscription fees, and limitless OS configurations straight out of the box.
- hAP ax³ with 4-core 1.8 GHz CPU, 1GB RAM, 4 x Gbit LAN, 1 x 2.5 Gbit LAN (supports PoE-in/out), two wireless interfaces (built-in 2.4 GHz 802.11b/g/n/ax dual-chain, built-in 5 GHz 802.11a/n/ac/ax dual-chain), 3.3dBi 2.4GHz external antenna, 5.5dBi 5GHz external antenna, tower/desktop case, USB, PSU, RouterOS L6
Technical Specifications
| Product Code | C53UiG+5HPaxD2HPaxD (hAP ax³) |
|---|---|
| CPU | IPQ-6010 Quad-Core 1.8 GHz ARM 64-bit |
| RAM Size | 1 GB |
| Storage | 128 MB NAND |
| Ethernet Ports | 4x 10/100/1000 Mbps ports, 1x 2.5 GbE port |
| Wireless 2.4 GHz | 802.11b/g/n/ax dual-chain (Wi-Fi 6) |
| Wireless 5 GHz | 802.11a/n/ac/ax dual-chain (Wi-Fi 6, max gain 5.5 dBi) |
| PoE & Power Options | DC Jack (12–28V), Passive PoE-in (18–28V), PoE-out on Ether1 |
| USB Port | 1x USB 3.0 type A |
| Operating System | RouterOS v7 (License Level 6) |
