Description
Engineered for Performance: The Perfect Foundation for 12th, 13th & 14th Gen Intel Builds
Unlock the full potential of your next desktop PC setup with the ASUS Prime B760-PLUS D4 Intel B760 LGA 1700 ATX Motherboard. Expertly engineered to support 12th, 13th, and 14th Generation Intel Core processors, this motherboard combines a robust power design, comprehensive cooling solutions, and intelligent tuning options. Whether you are building a high-speed productivity workstation or a responsive gaming rig, the Prime B760-PLUS D4 provides a rock-solid, future-proof foundation.
Key Features
- Intel LGA 1700 Socket Compatibility: Ready to unleash peak multi-core performance from 12th, 13th, and 14th Gen Intel Core, Pentium Gold, and Celeron desktop processors.
- Next-Gen PCIe 5.0 Express Slot: Future-proof your graphics performance. The primary x16 expansion slot features PCIe 5.0 architecture, delivering twice the data transfer speed of PCIe 4.0 to effortlessly handle modern, high-load GPUs.
- Ultrafast Storage Options: Equipped with three onboard M.2 slots—including two supporting hyper-fast PCIe 4.0 x4 modes—enabling lightning-fast boot times and rapid data loading for expansive application libraries.
- Comprehensive Cooling Controls: Built with robust VRM, M.2, and PCH heatsinks to prevent thermal throttling. Configure and monitor your thermal signatures completely via the intuitive Fan Xpert 2+ software ecosystem or the custom ASUS UEFI BIOS interface.
- High-Speed 2.5Gb Ethernet & Advanced Connectivity: Experience lag-free gaming and lightning-fast file transfers with integrated Realtek 2.5Gb High-Speed Ethernet. Features a versatile rear-panel USB 3.2 Gen 2x2 Type-C connector pushing ultra-fast transfer speeds up to 20 Gbps.
- ASUS Aura Sync RGB Customization: Personalize your system aesthetics with onboard Addressable Gen 2 headers and a classic Aura RGB layout, easily syncing colors across your entire portfolio of Aura Sync-capable peripherals.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | ASUS |
| Series / Model | PRIME B760-PLUS D4 |
| CPU Socket Type | LGA 1700 |
| Chipset | Intel B760 |
| Memory Support | 4x DDR4 DIMM Slots (Max 128GB), Up to DDR4 5066(OC) |
| Expansion Slots | 1 x PCIe 5.0 x16 slot, 1 x PCIe 4.0 x16 slot (x4 mode), 2 x PCIe 3.0 x1 slots |
| Storage Slots | 3 x M.2 Slots (Key M), 4 x SATA 6Gb/s Ports |
| Networking LAN | 1 x Realtek 2.5Gb Ethernet Port |
| Rear USB Ports | 1x USB 3.2 Gen 2x2 (Type-C), 2x USB 3.2 Gen 2 (Type-A), 1x USB 3.2 Gen 1, 2x USB 2.0 |
| Display Interfaces | 1 x DisplayPort 1.4, 1 x HDMI 2.1, 1 x VGA port |
| Form Factor | ATX Form Factor (30.5 cm x 24.4 cm) |
Official ASUS Prime Series Motherboard Showcase
Watch how the ASUS Prime Series Motherboards balance precise digital control with robust connectivity and cooling architecture to anchor commercial and performance DIY desktop systems:
