Description
Long-life Design
Excellent High Rate Discharge Performance
Low Self-discharge Rate
Best Compatibility With UPS
High Security
High Consistency
Convenient Installation and Maintenance
- Power rating: 15KVA/13.5KW
- Input wiring: Three phase or Single phase with ground(3:1 or 1:1)
- Input voltage range: 208VAC-476VAC(three phase)/120VAC-275VAC(signal phase)
- Input frequency range: 40-70Hz
- Output voltage: 220/230/240VAC
- Output frequency range: 50/60Hz+/-0.2Hz (battery mode)
- Battery voltage: 192VDC/216VDC/240VDC optional
- Battery quantity: default 16PCS (External), 16/18/20PCS adjustment
- Battery capacity and Backup time: Depends on customer configuration
- Recharge current: 4A
- LCD+LED: load rating/battery capacity/input/output/operating mode/Fault code
- Communication port: RS232 standard offer, USB optional
- Extendable communication card: Dry contact card, USB card, MODBUS card, NMC card are optional
- Product dimension(W*H*D): 248*500*565 mm
- Product weight: 31 kg
