Description
- Smartphone Gimbal & Wireless Receiver Specification
- Nominal Capacity: 900mAh
- Battery Type: Lithium-ion Polymer Battery
- Charging Time: Approx. 2 hrs (5V/1 A)
- Battery Life: 12 hrs
- Nominal Voltage: 3.7 V
- Charging Temperature: 5°C-40°C
- Connector: Type-C Charging Port
- Load Capacity (Reference Value): 1.0kg
- Angular Vibration Range: Roll Axis: ±0.1°
- Max Controllable Speed: Roll Axis: 180°/s
- Transmission Type: 2.4GHz
- Modulation: FSK
- Operating Range (without obstacles): 30m
- Audio Output Connector: 3.5mm Jack
- Operating Current: 0.3A~1.7A
- Weight: 269.5g
- Dimensions: 202 × 35 × 75.5 mm
- Wireless Transmitter Specification
- Transmission Type: 2.4GHz
- Modulation: FSK
- Operating Range (without obstacles): 30m
- Polar Pattern: Omnidirectional
- Frequency Response: 50Hz-12kHz
- Maximum SPL: Built-in Microphone:115dB SPL, Lavalier Microphone: 115dB SPL
- Sensitivity: Built-in Microphone: -39dB, Lavalier Microphone: -36.5dB
- Signal to Noise Ratio: >70dB
- Power Requirements: 3.7V Built-in Li-ion Battery
- Charging Time: Approx. 2hrs (5V/1 A)
- Battery Life: 3hrs
- Audio Input Connector: 3.5mm Mic In Jack
- Weight: 16.0g
- Dimensions: 56 × 24.2 × 21.85mm
BOYA BY-X1U Smartphone Gimbal & Wireless Microphone For Android Type-C Phone
BY-X1 is a single-axis smartphone gimbal and a wireless microphone system at the same time. The gimbal providing motorized roll motion control for smartphone to keep horizon stable, and the it designed with a wireless microphone receiver inside, combine with the wireless transmitter, the whole system is ideal for live steaming, vlogging, selfie shooting, tutorial recording and more!
