ASUS ROG Strix RTX 4080 OC Edition 16GB GDDR6X
NVIDIA Ada Lovelace Streaming Multiprocessors: Up to 2x performance and power efficiency
4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
3rd Generation RT Cores: Up to 2X ray tracing performance
OC mode: 2655 MHz (OC mode)/ 2625 MHz (Default mode)
Axial-tech fans scaled up for 23% more airflow
New patented vapor chamber with milled heatspreader for lower GPU temps
3.5-slot design: massive fin array optimized for airflow from the three Axial-tech fans
Diecast shroud, frame, and backplate add rigidity and are vented to further maximize airflow and heat dissipation
Digital power control with high-current power stages and 15K capacitors to fuel maximum performance
Auto-Extreme precision automated manufacturing for higher reliability
GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring
- ROG Strix GeForce RTX™ 4080 16GB GDDR6X OC Edition
- Graphic Engine: NVIDIA® GeForce RTX™ 4080
- Bus Standard: PCI Express 4.0
- OpenGL: OpenGL®4.6
- Video Memory: 16GB GDDR6X
- Engine Clock
- OC mode: 2655 MHz
- Default mode: 2625 MHz (Boost Clock)
- CUDA Core: 9728
- Memory Speed: 22.4 Gbps
- Memory Interface: 256-bit
- Resolution: Digital Max Resolution 7680 x 4320
- Interface
- Yes x 2 (Native HDMI 2.1a)
- Yes x 3 (Native DisplayPort 1.4a)
- HDCP Support Yes (2.3)
- Maximum Display Support: 4
- NVlink/ Crossfire Support: No
- Dimensions: 357.6 x 149.3 x 70.1mm
- Recommended PSU: 750W
- Power Connectors: 1 x 16-pin
- Slot: 3.5 Slot
- AURA SYNC: ARGB
- Warranty: 3 Years
WITH THE INCREDIBLE SUM OF ITS PARTS
The ROG Strix GeForce RTX™ 4080 brings a whole new meaning to going with the flow.
Inside and out, every element of the card gives the monstrous GPU headroom to breathe freely and achieve ultimate performance.
The unleashed reign of the NVIDIA Ada Lovelace architecture is here.
Axial-tech Upgrades
A Fresh Spin
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 23% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.
